Nitrogen8M Mini SMARC

Recommended for New Design (RND)

Overview

Assembled in USA
Get SOM Support+

Click here to learn more about our Universal SMARC Carrier board.

Our customers asked for a high performance, robust SoM that simplifies their BOM, has reliable connectivity, uses a standard form factor, and is globally certified. One with multiple software options, a proven security architecture, long term software support, and security fixes.

Our new Nitrogen8M Mini SMARC is powered by NXP’s class-leading i.MX 8M Mini processor, NXP PMIC PF8121, and our Sona WiFi 6/6E and Bluetooth 5.3/5.4 wireless module families based on leading NXP and Infineon solutions, high performance LPDDR4 RAM, and eMMC storage. We combine this with our common SMARC carrier board; together they can serve as a single board computer (SBC) that can speed your product to market. Alternately, work with us to create a custom carrier that fits your mechanical, environmental, temperature, and interface requirements.

  • Powerful Heterogenous Multiprocessing: Up to 1.8 GHz quad-core Cortex-A53 microprocessor and 400 MHz Cortex-M4 microcontroller allow you to run Linux and an RTOS on dedicated, hardware-firewalled subsystems.
  • Diversity of Interfaces: Display, network, data, audio and camera interfaces.
  • SMARC 2.1.1 Standard Form Factor: 82mm x 50mm SMARC edge connector form factor which includes onboard ethernet PHY and a USB hub controller. One design supports multiple processor, memory, and wireless configurations.
  • Hardware Upgrade Roadmap: Build a product design that can easily be upgraded to the latest processors and wireless options as future Ezurio (formerly Laird Connectivity) SOMs based on the SMARC standard are released.
  • Advanced Common Carrier/Development Board: Display, camera, audio, Ethernet, USB, PCI-Express, I2C, SPI, UART, and more. Use in development, as an SBC equivalent in a product, or as reference designs for your carrier board design.


Custom Solutions

Reduce design risk and accelerate your time to market with Ezurio's custom Single Board Computers (SBC). We offer:

  • A hand-in-hand partnership approach.
  • Design your board your way.
  • Lower production costs by choosing your required components.
  • Industry leading hardware and software.

Learn More

Custom SBC for SOM pages.png

Specifications

Chipset (MPU)
4x Cortex®-A53 cores @ up to 1.8 GHz (NXP i.MX 8M Mini)
Chipset (MCU)
1x Cortex®-M4 core @ 400 MHz (NXP i.MX 8M Mini)
Wireless Specification
(optional)
Wi-Fi 6/6E
Bluetooth 5.3/5.4
Dimension (Length - mm)
82
Dimension (Width - mm)
50
Memory
1GB, 2GB, or 4GB LPDDR4
Form Factor
SMARC Connector
Audio
2x 12S
Camera
1x MIPI-CSI
I2C
5x I2C
Interfaces - General
1x PCIe
3x USB2
1x GbE
1x SDIO/eMMC
I2C
SPI
UART
GPIO
Operating Temperature
0°C to +70°C (commercial)
-40°C to +85°C (industrial)
Storage
16 GB
Part NumberMemoryOperating Temp (Max) (°C)Operating Temp (Min) (°C)Storage
Nitrogen8M Mini SMARC - without wireless
8MM_SMARC_SOM_2r16eBuy Now
2 GB +70 °C+0 °C16 GB
Nitrogen8M Mini SMARC - without wireless
8MM_SMARC_SOM_4r16e
Under Development
Buy Now
4 GB +70 °C+0 °C16 GB
Nitrogen8M Mini SMARC - without wireless
8MM_SMARC_SOM_1r16e_i
Under Development
1 GB +85 °C-40 °C16 GB
Nitrogen8M Mini SMARC - without wireless
8MM_SMARC_SOM_2r16e_i
Under Development
Buy Now
2 GB +85 °C-40 °C16 GB
Nitrogen8M Mini SMARC - without wireless
8MM_SMARC_SOM_4r16e_i
Under Development
Buy Now
4 GB +85 °C-40 °C16 GB

Documentation

Name Part Type Last Updated
Product Brief - Nitrogen8M Mini SMARC All Product Brief 04/12/2024
3D Model and STEP File - Nitrogen8M Mini SMARC All Technical Drawings 01/25/2024
User Guide - Nitrogen8M Mini SMARC All Documentation 01/02/2024
Wiki - Nitrogen8M Mini SMARC (External Link) All Documentation 01/09/2024
Datasheet - Nitrogen8M Mini SMARC All Datasheet 01/25/2024
Software Wiki - Nitrogen8M Mini SMARC (External Link) All Software 03/19/2024
