Tungsten510 SMARC

Under Development: Preview

Overview

Assembled In USA
Get SOM Support+

Click here to learn more about our Universal SMARC Carrier board.

Our new Tungsten510 is powered by MediaTek’s Genio 510 processor and our Sona™ MT320 Wi-Fi 6 / Bluetooth 5.3 radio based on MediaTek’s Filogic 320 (MT7921), high performance LPDDR4 RAM, and eMMC storage. In combination with our universal SMARC carrier board, they are a single board computer (SBC) that can speed your product to market. Alternately, work with us to create a custom carrier that fits your mechanical, environmental, temperature, and interface requirements.

  • Powerful Arm DynamIQ big.LITTLE Multiprocessing: Dual-core 2.0 GHz Cortex-A78 and quad-core 2.0 GHz Cortex-A55 balances power efficiency via the little A55 cores with the peak computing performance provided by the big A78 cores.
  • High Performance Graphics and Display powered by an Arm Mali-G57 MC2 GPU and dual display outputs supporting 4K60 plus FHD60 resolution, allowing for smartphone and tablet class UIs and 3D performance.
  • 4K Video Encoder and Decoder with encoding support for 4K30 in HEVC/H.264 and decoding of up to 4K60 in HEVC/H.264/AV1/VP9.
  • Tensilica HiFi 5 Audio DSP for efficient processing of audio codecs and voice data.
  • Dedicated MediaTek AI Accelerator: High-performance edge machine learning via an integrated neural processing unit, delivering up to 2.8 TOPS.
  • Advanced Vision Pipeline: multiple MIPI-CSI, onboard image signal processor (up to 32MP @ 30 fps) for functions like electronic image stabilization and HDR fusion, and a Tensilica VP6 vision processing unit capable of face detection, object identification, scene analysis, optical character recognition, and more.
  • Diversity of Interfaces: Multiple display, network, data, audio and camera interfaces.
  • Optional Wi-Fi 6 (802.11ax) and Bluetooth 5.3 Classic & Low Energy (LE)

Custom Solutions

Reduce design risk and accelerate your time to market with Ezurio's custom Single Board Computers (SBC). We offer:

  • A hand-in-hand partnership approach.
  • Design your board your way.
  • Lower production costs by choosing your required components.
  • Industry leading hardware and software.

Learn More

Custom SBC for SOM pages.png

Specifications

Chipset (MPU)
2x Cortex-A78 @ up to 2.0 GHz
+ 4x Cortex-A55 @ up to 2.0 GHz
(MediaTek Genio 510)
Wireless Specification
Wi-Fi 6 (802.11ax)
Bluetooth 5.3
Dimension (Length - mm)
82
Dimension (Width - mm)
50
Additional Features
2D Accelerator, 2.8TOPS NPU
Interfaces - General
USB 3.0, USB 2.0, Gbit Ethernet, UART, I2C, SPI, SDIO/eMMC, GPIO
MIPI-CSI, MIPI-DSI
Audio via I2S
Memory
4 or 8 GB LPDDR4 RAM
16 GB eMMC
Operating Temperature
0 to +70C (Commercial)
-40 to +85C (Industrial)
Region
FCC/IC/CE/MIC/RCM (pending)
Part NumberAdditional DescriptionMemoryOperating Temp (Max) (°C)Operating Temp (Min) (°C)Storage
Universal SMARC Carrier
SMARC_CAR_BRD
Recommended for New Design (RND)
Buy Now
Universal SMARC Carrier Board
Tungsten510 SMARC
T510_SMARC_SOM_4r16eBuy Now
4GB +70 °C+0 °C16 GB
Tungsten510 SMARC
T510_SMARC_SOM_8r16eBuy Now
8GB +70 °C+0 °C16 GB
SMARC_CAR
SMARC_CAR
Recommended for New Design (RND)
Buy Now
Kit - Universal SMARC Carrier Board. Includes antennas, power supply, DB9 cable

Documentation

Name Part Type Last Updated
Product Brief - Tungsten510 SMARC All Product Brief 03/27/2024
Wiki - Tungsten510 SMARC (External Link) All Documentation 03/19/2024
Software Wiki - Tungsten510 SMARC (External Link) All Software 03/19/2024
User Guide - Tungsten510 SMARC (External Link) All Documentation 03/19/2024
Datasheet - Universal SMARC Carrier REV1 All Datasheet 06/13/2024
3D Model and STEP File - Tungsten510 All Technical Drawings 03/20/2024
Datasheet - Tungsten510 SMARC (Preliminary) All Datasheet 06/13/2024

FAQ

What is the difference between part numbers SMARC_CAR and SMARC_CAR_BRD

Our Universal SMARC Carrier is orderable both as a standalone carrier board (SMARC_CAR_BRD) and as a kit (SMARC_CAR) complete with power, data, and antenna cable options.

  • The part # SMARC_CAR option includes:
  • 1 x SMARC_CAR_BRD  (Main Carrier board that SMARC SOMs plug into)
  • 1 x 5V Power Supply (USA plug connector only)
  • 1 x DB9 Serial Cable
  • 3 x EFB2471A3S-10MH4L (Tri-Band Wi-Fi Antennas)
  • 2 x 001-0021 (Dual-Band Wi-Fi Antennas)
  • 1 x Insert Card

The part # SMARC_CAR_BRD is also purchasable on its own and this is the main carrier board.

PLEASE NOTE – neither of these 2 part numbers include either a Nitrogen or Tungsten SMARC, they are purchased separately to meet the needs of your application.

What key is the M.2 slot on the Universal SMARC Carrier board?

The M.2 Slot on the Universal SMARC Carrier board is E key.
