Tungsten700 SMARC
Overview
Click here to learn more about our Universal SMARC Carrier board.
Our new Tungsten700 SMARC (What is SMARC?) is powered by MediaTek’s Genio 700 processor and our optional Sona™ MT320 Wi-Fi 6 / Bluetooth 5.4 radio based on MediaTek’s Filogic 320 (MT7921), high performance LPDDR4 RAM, and eMMC storage. In combination with our universal SMARC carrier board, they are a single board computer (SBC) that can speed your product to market. Alternately, work with us to create a custom carrier that fits your mechanical, environmental, temperature, and interface requirements.
- Powerful ARM DynamIQ big.LITTLE Multiprocessing: Dual-core 2.2 GHz Cortex-A78 and hexa-core 2.0 GHz Cortex-A55 balances power efficiency via the little A55 cores with the peak computing performance provided by the big A78 cores.
- High Performance Graphics and Display powered by an Arm Mali-G57 MC3 GPU and dual display outputs supporting 4K30 plus 4K60 resolution, allowing for smartphone and tablet class UIs and 3D performance.
- 4K Video Encoder and Decoder with encoding support for 4K30 in HEVC/H.264 and decoding of up to 4K75 in HEVC/H.264/AV1/VP9.
- Tensilica HiFi 5 Audio DSP for efficient processing of audio codecs and voice data.
- Dedicated MediaTek AI Accelerator: High-performance edge machine learning via an integrated neural processing unit, delivering up to 3.7 TOPS.
- Advanced Vision Pipeline: multiple MIPI-CSI, onboard image signal processor (up to 32MP @ 30 fps) for functions like electronic image stabilization and HDR fusion, and a Tensilica VP6 vision processing unit capable of face detection, object identification, scene analysis, optical character recognition, and more.
- Diversity of Interfaces: Multiple display, network, data, audio and camera interfaces.
- Optional Wi-Fi 6 (802.11ax) and Bluetooth 5.4 Classic & Low Energy (LE)
Watch Video
Optional Wi-Fi 6 +
Bluetooth 5.4
Excellent Wi-Fi and BT Classic / LE connectivity in difficult environments, plus enterprise Wi-Fi support via WPA3-Enterprise for more secure and robust connections.
ML, Graphics, Video and Audio - Up To 2 Displays
3.7 TOPS Machine Learning/Neural Processing Unit, up to 4kp30 or 4Kp60 displays, high-performance Arm Mali-G57 MC3 GPU, 4K multi codec encode and decode VPU, multiple MIPI-CSI camera up to 32MP @ 30 fps, Tensilica VP6 VPU, Tensilica HiFI 5 audio DSP
Powerful Arm DynamIQ big.LITTLE Multiprocessing
Dual-core 2.2 GHz Cortex-A78 and hexa-core 2.0 GHz Cortex-A55 balances power efficiency via the little A55 cores with the peak computing performance provided by the big A78 cores
Custom Solutions
Reduce design risk and accelerate your time to market with Ezurio's custom Single Board Computers (SBC). We offer:
- A hand-in-hand partnership approach.
- Design your board your way.
- Lower production costs by choosing your required components.
- Industry leading hardware and software.
Specifications
+ 6x Cortex-A55 @ up to 2.0 GHz
(MediaTek Genio 700)
Bluetooth 5.4
MIPI-CSI, MIPI-DSI
Audio via I2S
16 GB eMMC
-40 to +85C
Part Number | Additional Description | Memory | Operating Temp (Max) (°C) | Operating Temp (Min) (°C) | Part Group | Storage |
---|---|---|---|---|---|---|
SMARC_CAR Recommended for New Design (RND) Buy Now | Kit - Universal SMARC Carrier Board. Includes antennas, power supply, DB9 cable | Carrier Board | ||||
SMARC_CAR_BRD Recommended for New Design (RND) Buy Now | Universal SMARC Carrier Board | Carrier Board | ||||
T700_SMARC_SOM_4r16e Recommended for New Design (RND) Buy Now | Tungsten700 SMARC (without wireless) | 4GB | +70 °C | +0 °C | 16 GB | |
T700_SMARC_SOM_4r16e_MT320_2M Recommended for New Design (RND) Buy Now | Tungsten700 SMARC (with Sona MT320 Wi-Fi 6 + Bluetooth® 5.4) | 4GB | +70 °C | +0 °C | 16 GB | |
T700_SMARC_SOM_4r16e_MT320_2M_i Recommended for New Design (RND) | Tungsten700 SMARC (with Sona MT320 Wi-Fi 6 + Bluetooth® 5.4) | 4GB | +85 °C | -40 °C | 16 GB | |
T700_SMARC_SOM_4r16e_i Recommended for New Design (RND) | Tungsten700 SMARC (without wireless) | 4GB | +85 °C | -40 °C | 16 GB | |
T700_SMARC_SOM_8r16e Recommended for New Design (RND) Buy Now | Tungsten700 SMARC (without wireless) | 8GB | +70 °C | +0 °C | 16 GB | |
T700_SMARC_SOM_8r16e_MT320_2M Recommended for New Design (RND) | Tungsten700 SMARC (with Sona MT320 Wi-Fi 6 + Bluetooth® 5.4) | 8GB | +70 °C | +0 °C | 16 GB | |
T700_SMARC_SOM_8r16e_MT320_2M_i Recommended for New Design (RND) Buy Now | Tungsten700 SMARC (with Sona MT320 Wi-Fi 6 + Bluetooth® 5.4) | 8GB | +85 °C | -40 °C | 16 GB | |
T700_SMARC_SOM_8r16e_i Recommended for New Design (RND) Buy Now | Tungsten700 SMARC (without wireless) | 8GB | +85 °C | -40 °C | 16 GB |
Documentation
Name | Part | Type | Last Updated |
---|---|---|---|
Product Brief - Tungsten700 | All | Product Brief | 09/18/2024 |
Datasheet - Tungsten700 SMARC | All | Datasheet | 12/05/2024 |
Wiki - Tungsten700 SMARC (External Link) | All | Documentation | 11/16/2023 |
Software Wiki - Tungsten 700 SMARC (External Link) | All | Software | 11/28/2023 |
Application Note - How to recover a Tungsten700 SMARC | All | Application Note | 11/27/2023 |
User Guide - Tungsten700 SMARC SOM (External Link) | All | Documentation | 11/29/2023 |
3D Model and STEP File - Tungsten700 SMARC | All | Technical Drawings | 09/23/2024 |
Datasheet - Universal SMARC Carrier | All | Datasheet | 12/05/2024 |
PCN # 2B-2024 - Tungsten 700 SMARC | All | Documentation | 03/29/2024 |
PCN 5D-2024 - SOMs and SBCs | All | Documentation | 07/08/2024 |
What is the difference between part numbers SMARC_CAR and SMARC_CAR_BRD
Our Universal SMARC Carrier is orderable both as a standalone carrier board (SMARC_CAR_BRD) and as a kit (SMARC_CAR) complete with power, data, and antenna cable options.
- The part # SMARC_CAR option includes:
- 1 x SMARC_CAR_BRD (Main Carrier board that SMARC SOMs plug into)
- 1 x 5V Power Supply (USA plug connector only)
- 1 x DB9 Serial Cable
- 3 x EFB2471A3S-10MH4L (Tri-Band Wi-Fi Antennas)
- 2 x 001-0021 (Dual-Band Wi-Fi Antennas)
- 1 x Insert Card
The part # SMARC_CAR_BRD is also purchasable on its own and this is the main carrier board.
PLEASE NOTE – neither of these 2 part numbers include either a Nitrogen or Tungsten SMARC, they are purchased separately to meet the needs of your application.
What audio codec does the Tungsten 700 use?
The Tungsten 700 SMARC uses the WM8962 audio codec. Support for this audio codec is included in the source code and the pre-compiled images.
How do I set the bootloader back to its default configuration?
The command env erase
will restore defaults when executed in the bootloader.
How do I configure my network connection?
NMCLI should be utilized to configure network interfaces.
What key is the M.2 slot on the Universal SMARC Carrier board?
The M.2 Slot on the Universal SMARC Carrier board is E key.
